THIS IS A SKETCH OF AN AS-BUILT SURVEY OF:
Lots 233 through 237 inclusive, Amended First Ocean Front Subdivision, according to the Plat thereof, as recorded in Plat Book 9, at page 78 of the public records of Dade County, Florida. Said Lots bounded on the East by the Erosion Control Line of the Atlantic Ocean, said Line recorded in Plat Book 105, at page 62 of the public records of Dade County, Florida.
AND
All that parcel of land bounded on the North by the North line of Lot 237 produced Westerly;
Bounded on the South by the South line of Lot 233 produced Westerly;
Bounded on the East by the Westerly line of Lots 233 through 237 inclusive, or, the Easterly line of Collins Avenue, as said Lots and Avenue are shown on the Amended First Ocean Front Subdivision, recorded in Plat Book 9, at page 78 of the public records of Dade County, Florida.
Bounded on the West by the Easterly right-of-way line of realigned Collins Avenue (130 feet wide), said Easterly right-of-way line being described as follows:
Commencing (P.O.C.) at the intersection of the N.W. corner of Lot 28 and the Easterly right-of-way line of Collins Avenue as shown on the above mentioned Record Plat, run N.16"57'30"E., along the Easterly right-of-way line of Collins Avenue as shown on the said recorded plat, a distance of 59.752 feet to a point, said point being the Point of Curvature (P.C.) of a Circular Curve concave to the Southeast, said point also being the Point of Commencement of the realigned Collins Avenue; thence run Northeasterly along the said Easterly right-of-way line of Collins Avenue, along the Arc of said Circular Curve having for its elements a Central Angle of 14"31'23.675", a Radius of 1141.227 feet, a distance of 289.28 feet to the Point of Reverse Curvature (P.R.C.) of a Circular Curve concave to the West; thence continue along the right-of-way line of realigned Collins Avenue, along the Arc of said Reverse Curve concave to the West, having for its elements a Central Angle of 31"00'53.675", a Radius of 1271.227 feet, a distance of 688.13 feet to the Point of Tangency (P.T.) of said Reverse Curve, said point being on the Easterly right-of-way line of said Collins Avenue, and on the Westerly line of Lot 238, as said Avenue and Lot are shown on the above mentioned recorded plat, said point also being 26.549 feet Southerly of [gap in scan] the Northerly line of said Lot 238, as measured along the Easterly right-of-way line of Collins Avenue as shown on said recorded plat.
The above described property contains 172,547 square feet, more or less, or 3.96 acres, more or less.
SURVEYORS CERTIFICATE:
WE HEREBY CERTIFY: that the "Sketch of Survey" shown hereon is true and correct to the best of our knowledge and belief, as recently surveyed under our direction; also that there are no visible encroachments, unless shown hereon. Examination of the "abstract of Title" will have to be made to determine recorded instruments, if any, which may affect this property. This survey conforms to the minimum technical standards for Land Surveys in the State of Florida, pursuant to Section 472.027, Florida Statutes and to Chapter 21HH-6 of the Florida Administrative Code, as adopted by the Department of Professional Regulation, Board of Land Surveyors. This "Sketch of Survey" is not valid unless the embossed seal of a Professional Land Surveyor, employed by Zurwelle-Whittaker, Inc., is affixed hereon.
ORDER NO. 78274-91. Zurwelle-Whittaker, Inc. By: [signature] James D. Reeves, President, P.L.S. No. 2194 [digit partly obscured], Florida.
CASTLE BEACH CLUB, A CONDOMINIUM. Zurwelle-Whittaker, Inc., Engineers & Surveyors, 605 Lincoln Road, Suite 506, Miami Beach, Florida. October 19, 1991. Sheet 2A of 40.
