OR 15842/2257

Revised LOBBY FLOOR survey sheet (rotated in scan). Shows CU-1 and the enlarged CU-2 (now including the oval south-end area where former L-7 and L-8 were), the new CU-2A (small unit near the curve), CU-14, CU-15, BAY-1 through BAY-7 on the west, TH-1 through TH-17 row on the east with L.C.E. balconies, P-1 through P-4 footprints southeast, L-1 through L-6 remaining around the curve, hatched common-element lobby and L.C.E. areas. Notes: "TH UNITS 1 THRU 17 INCLUSIVE ARE IN PLACE (INTERIORS TO BE CONSTRUCTED). P UNITS 1 THRU 4 INCLUSIVE, L UNITS 1 THRU 6 INCLUSIVE AND BAY UNITS 1 THRU 6 INCLUSIVE ARE TO BE CONSTRUCTED AS SHOWN HEREON. C U INDICATES COMMERCIAL UNITS. L.C.E. INDICATES A LIMITED COMMON ELEMENT. C E INDICATES A COMMON ELEMENT." Margin notes: "C U Units 2 & 2 A Revised: 3-11-93"; "Proposed Unit L 7 & L 8 ARE eliminated" [partly handwritten]. Clerk note: FOR DECLARATION OF CONDOMINIUM SEE OFFICIAL RECORD BK 15842 PG 2255. Scale in feet; north arrow. Zurwelle-Whittaker, Inc., October 15, 1991, Sheet 8 of 40. [Surveyor's embossed seal and signature.]
